PL-72 Wheelchair Vertical Platform Lift

Extended Rise Wheelchair Lift

PL-72 Residential Wheelchair Lift for Higher Elevations

The PL-72 residential wheelchair lift delivers up to 72 inches of vertical travel, making it the ideal solution for elevated home entrances and larger height transitions. When ramps become too long or space becomes limited, this vertical platform lift provides a clean, efficient alternative.

Whether installed outdoors at a raised porch or indoors for garage-to-home access, the PL-72 offers dependable operation and a streamlined footprint for homes requiring extended rise capability.

PL-72 residential wheelchair lift installed at elevated home entry

Precision Screw-Drive Lift Mechanism

The PL-72 relies on a precision screw-drive system that delivers steady, controlled vertical movement across the full 72-inch travel range. This design minimizes exposed mechanical components and reduces maintenance compared to chain-driven alternatives.

Adaptable Platform Entry Configurations

The PL-72 accommodates two entry layouts to match your site conditions:

Straight-Through – Board and exit on opposite sides
90° Entry – Board and exit at a right angle

This adaptability is especially useful for higher landings and split-level transitions where space is limited.

Ergonomic Platform Controls

Clearly labeled directional buttons are mounted directly on the platform for convenient, one-touch operation. Oversized contact areas make the controls accessible to users with limited hand dexterity or mobility.

Integrated Residential Safety Systems

The PL-72 includes a keyed lockout switch to restrict unauthorized access and a platform-mounted emergency stop for immediate response. These systems work together to provide consistent, reliable safety across every cycle.

Dual-Level Height Control & Redundancy

Primary limit switches set the upper and lower stopping points, while independent secondary limits provide a built-in backup layer. This dual-level approach ensures the platform stops precisely and consistently, even under extended daily use.

Optional Backup Power System

The PL-72 runs on standard 120V household power. An optional battery backup module is available for continued limited operation during power outages, helping ensure accessibility is not interrupted when it matters most.

For homeowners requiring greater vertical reach, the PL-72 provides a durable and space-conscious residential wheelchair lift solution. Frequently selected as a porch lift or elevated deck access system, it delivers dependable vertical transportation without the complexity of a traditional home elevator.

Frequently Asked Questions

The PL-72 vertical platform lift provides up to 72 inches of rise, making it suitable for higher entry points, elevated decks, and split-level residential applications.

The PL-72 is designed for homes with taller elevation changes that exceed the range of a standard lift. Common applications include raised front porches, multi-step garage entries, and elevated rear decks where ramps would be excessively long.

Yes. The PL-72 is constructed with weather-resistant materials and is designed for reliable operation in both indoor and outdoor environments year-round.

No. The PL-72 is a vertical wheelchair lift designed specifically for accessibility and moderate vertical travel. It does not require a shaft, pit, or the structural modifications associated with a traditional home elevator.

The PL-72 supports up to 750 pounds, accommodating most power wheelchairs and mobility scooters along with the user.

Yes. The PL-72 is frequently installed at garage-to-home transitions where multiple steps create an access barrier. Both straight-through and 90° configurations are available to match common garage layouts.
